Customized Cylinder Shaft Axle For Telescopic Cylinder Walking / Chassis Mechanisms

Name: Customized Cylinder Shaft Axle For Telescopic Cylinder Walking Chassis Mechanisms
Brand: MEGE/OEM/ODM/CUSTOMIZED
Price: 1 USD

Brand Name : MEGE/OEM/ODM/CUSTOMIZED

Model Number : CUSTOMIZED

Certification : ISO9001-2016

Place of Origin : CHINA

MOQ : 1 pcs

Price : Reasonable Price

Payment Terms : L/C, T/T, D/P, D/A, Western Union, MoneyGram

Supply Ability : 500000pcs/month

Delivery Time : 15-30 Days depends on quantity needed

Packaging Details : Foam, Carton, Wooden Box or as requirement.

Material : 42CrMo/35CrMo alloy steel/Quenched & Tempered to 241-285 HBW

Max Weight : Max single-piece weight: 1.12 tons

Hardeness : 241-285 HBW (quenched & tempered)

Surface Treatment : 45-55 HRC (quenched) chrome-plated (20-50μm) for wear/corrosion resistance

Precision : Tolerance control from -0.36mm to -0.59mm

Features : High-Strength Forged Construction/Precision Machining/Corrosion Protection/Heavy-Duty Design

Application Area : Customized/Excavator/Crane traveling systems/Paver chassis mechanisms/Heavy-duty construction machinery walking assemblies

HS Code : --

Seal : Boss structures for retaining/sealing rings to prevent axial movement and dust ingress

Function : Cylinder force transmission/Axial positioning/Sealing protection

Contact Now

Product Profile: Heavy-Duty Traveling Mechanism Shaft - Telescopic cylinder Shaft

A critical force-transmission component connecting telescopic cylinders to walking systems in excavators, cranes, pavers, and other construction machinery. Engineered to convert cylinder thrust/pull into precise linear motion while withstanding extreme operational stresses.

Key Features:
✔ High-Strength Material – 42CrMo/35CrMo alloy steel, quenched & tempered to 241-285 HBW
✔ Surface Optimization – Quenched to 45-55 HRC + chrome-plated (20-50μm) for wear/corrosion resistance
✔ Integrated Sealing Design – Boss structures for retaining/sealing rings to prevent axial movement and dust ingress
✔ Force Transmission – Efficiently transfers cylinder extension/retraction forces to traveling mechanisms

Technical Specifications:

Materials: 42CrMo, 35CrMo
Core Hardness: 241-285 HBW (quenched & tempered)
Surface Hardness: 45-55 HRC (quenched)
Chrome Plating: 20-50μm
Function: Cylinder force transmission, axial positioning, sealing protection

Applications:

Excavator/crane traveling systems
Paver chassis mechanisms
Heavy-duty construction machinery walking assemblies

Why Choose This Shaft:

Dual hardness profile balances strength and toughness
Chrome plating ensures longevity in outdoor environments
Sealing integration reduces maintenance frequency
Precision-machined for reliable force transmission

At MEGE, we specialize in delivering high-quality, precision-engineered mechanical components customized to your specifications. With decades of experience in OEM/ODM manufacturing, we combine advanced engineering expertise with flexible production capabilities to meet your most demanding requirements.

FAQ

Q:Are you a trader or manufacturer?

A:We are factory specializing in all kind of bearings and machinery components. We own 20,000 meter square factory and have high productivity. We can give you the best price and better service.

Q: Why choose MEGE?

Our products are exported to multiple countries and regions overseas, more than 30 countries including Japan, Italy, Germany, Austria, Bangladesh, Malaysia, United Arab Emirates, India, etc.

We have Japanese Quality, Chinese factory price.

Q:What is your delivery time?

A:Sample order: Immediate delivery , bulk order: usually 30 days.

Q:Can i request sample?

A:Of course, we can give you a sample by free.

Q:What's the shipping way?

A:According to YOUR demands.

Q:Can you accept OEM or ODM?

A:Yes, of course. Both is ok.

Q:How is quality controlled?

A:Quality is the key!

Our QC team and engineer team works through all the process from an order placed to shipped.

Q: Can I come for a visit?

You are welcome to visit our four factories, office! Please contact our reception and we will make a schedule for you.
